BODY
BODY SHAPE- ML1 Baritone
- Ash Veneer On Flat Top with Satin Finish
- Alder with Satin Finish
NECK
HEADSTOCK- Angled Heritage Headstock
- Chapman Classic Closed (18:1 Gearing)
- 42mm Graph Tech Black TUSQ XL Nut
- Maple with Satin Finish
- Recessed Bolt-on Neck
- WIDTH: NUT 42mm, 24F 57mm
- THICKNESS including fret height: 1F 23.5mm 12F 25mm
- C Shape
- Dual Action
- Macassar Ebony Fretboard with Rolled Edges
- 350mm (~13.5″)
- 24 Jumbo Nickel Frets
- Pearl Side Dots and Pearl Front Dot Inlays
- Pearl Infinity
- 711mm (~28″)
ELECTRONICS
NECK PICKUP- Chapman Sonorous Zerø Baritone Humbucker
- MAGNET: Alnico 5
- OUTPUT: 12.5k ohms
- Chapman Sonorous Zerø Baritone Humbucker
- MAGNET: Alnico 5
- OUTPUT: 16.5k ohms
- 3 Way Blade Switch with Coil Split on Push-Pull Tone Knob
- Master Volume (500k), Master Tone with Push-Pull (500k)
HARDWARE
BRIDGE- Chapman String-Through Hardtail
- Chapman Classic Strap Buttons
- Ernie Ball Super Slinky, Nickel Wound, Custom 12-60
PICKUP SWITCHING
POSITION 1
Bridge
Bridge Split (Outer Coil)
POSITION 2
Bridge + Neck
Bridge + Neck Both Split (Outer Coil)
POSITION 3
Neck
Neck Split (Outer Coil)
